15A Solar Voltage Regulator With Multiple Battery Compatibility And
System Protection
Product Description:
With a maximum PV power of 285W at 12V and 570W at 24V, this
electric voltage solar regulator can handle a wide range of solar
panel configurations and output levels. The temperature
compensation feature ensures that your batteries are charged at the
optimal temperature, maximizing their performance and lifespan.
This PWM controller is compatible with a range of battery types,
including AGM, GEL, WET, Calcium, LiFePO4, and LTO. This makes it a
versatile choice for a variety of solar power applications, from
small off-grid systems to larger residential and commercial
installations.
The Digital Solar Charge Controller is built to last, with a
durable black casing that protects it from the elements. Its
user-friendly design makes it easy to install and operate, and its
advanced features ensure that your solar power system runs smoothly
and efficiently.
Features:
- Product Name: Digital Solar Charge Controller
- IP Level: IP22 or IP67
- Maximum Input Voltage: 50V
- Warranty: 2 Years
- Protection: Overcharge/Short Circuit/Reverse Polarity/Over
Temperature
- System Voltage: 12V 24V
- Keywords: solar charge regulator, solar voltage regulator, electric
voltage solar regulator
Technical Parameters:
| Item No. | MT515-15A |
| Rated Current | 15A |
| Max. Solar Power Input | 285W@12V system , 570W @24 |
| Norminal Solar Input Voltage | 15~44V DC |
| Max. Solar Input Voltage | 50V DC |
| Lowest Operation Voltage | 9V DC |
| Charging Stage | 5 Stage Charging (Soft Start-Bulk-Absorption-Equalization-Float) |
| Battery Type | 6 Types of Battery (AGM, GEL, WET ,Calciium,LTO & LiFePO4) |
| Min. Battery voltage | 3V DC |
| Protection | Over Charge , Input & Output Reverse Polarity , Short Circuit ,
Over temperature, |
| IP Rate | IP22 or IP67 |
| Mounting method | Wall mount |
| Size | 130X102.6X35mm |
| Weight | 250g |
| Operation Temperature | -25~50℃/-13~122℉ |
| Storage Temperature | -40~85℃/-40~185℉ |
Applications:
Manufactured in China, this digital solar charge controller has
been certified with CE, FCC, and UKCA, ensuring its quality and
safety. It has a minimum order quantity of 100, and a delivery time
of 25 days, with a supply ability of 5000pcs per month.
The MT515 Digital Solar Charge Controller has an IP level of either
IP22 or IP67, making it suitable for use in various weather
conditions. It has a rated current of 15A, and a maximum input
voltage of 50V. This smart solar regulator also has a BMS wake-up
feature, ensuring that it is always ready to function.
This solar voltage regulator is compatible with various battery
types, including AGM, GEL, WET, Calcium, LiFePO4, and LTO
batteries. This feature makes it an ideal choice for different
solar systems.
The MT515 Digital Solar Charge Controller is perfect for off-grid
solar systems, solar-powered streetlights, and solar-powered water
pumps. It is also suitable for use in RVs, boats, and other mobile
solar systems. This smart solar regulator can efficiently regulate
and manage the power produced by solar panels, ensuring the
longevity of the battery and system.
In summary, the Melin Sunergy MT515 Digital Solar Charge Controller
is a reliable and efficient device that can manage and regulate
solar power systems. Its compatibility with various battery types
and its ability to function in different scenarios make it a
versatile tool for any solar-powered system.
